New PC Cases Released for Compact ITX Builds

Mini-ITX has existed as a form factor since 2001, but for most of its life it demanded a real sacrifice: a short graphics card, a low-profile cooler jammed against a side panel, an SFX power supply wired into a space barely large enough to hold it, and thermals that ran hotter than anyone building an equivalent full tower would put up with. That calculus has shifted. 2026 is the point where the tradeoffs stopped being mandatory, and the reasons are mechanical.

The component ecosystem underneath the cases changed first, and that shift is what made the rest of these design changes possible. Most Mini-ITX cases released over the past few years now fit full-length, two- or three-slot graphics cards, the kind that used to be reserved for ATX towers. SFF-L power supply support, once a specialty item, is close to standard across the segment now. None of that was true a handful of years ago, and it means building small no longer means building compromised. That shift in what the hardware itself allows, not a marketing push, is the actual story here.

The r/sffpc subreddit has grown to 359,000 members, which tells you the audience paying attention to this shift is no longer a fringe group trading tips in a forum nobody reads. Supply is catching up to that audience, and it's catching up because the underlying parts finally allow it.

What new cases announced at Computex 2026 signal about the market

Computex 2026 turned into something of an inflection point for compact cases. Multiple manufacturers used the show to announce or showcase Mini-ITX and compact-adjacent products, and that alone tells you the segment moved from a side project to a competitive battleground. Three distinct directions emerged on the show floor, and they pull in different enough ways that no single one of them defines where the category is going.

Gigabyte showed off the Aorus C510 Glass Infinity, an mATX prototype that pushes hard into aesthetics. It builds a 16-inch, 1080p, 165Hz display directly into the side panel, usable as an actual second monitor, alongside modular feet that double as a carry handle and a chassis that converts to vertical orientation. Despite the mATX label, the case holds 25 liters of internal volume, supports radiators up to 240mm, and fits GPUs as long as 360mm. It reads like a case built for LAN parties and events as much as for a desk. Pricing and a release date remain unconfirmed, so treat it as a preview of direction rather than a buying option.

Geometric Future's Model 0 took the opposite approach: no screens, just structural invention. It's a folding case where the panels physically lie flat and wrap around the internal components, spotted at the show with detailed specifications still unconfirmed. That's an engineering experiment first and a product second, at least for now.

NZXT went the conservative route, showing an H2 Flow Mini-ITX offering in a new white colorway with no price change announced. That's not a headline by itself, but it says something real about the market: refinement and colorway expansion now counts as a legitimate competitive move in a segment that used to compete almost entirely on internal volume and airflow numbers.

Putting the three together, they say the same thing from different angles. Manufacturers have stopped competing only on how much they can cram into a small box. They're competing on how that box looks on a desk, how it travels, and how it feels to own. Aesthetics have become a primary design brief in ITX, and any case launched from here forward is going to get judged on that basis regardless of its maker's intent.

Four cases you can buy now, and what each one prioritizes

Skip the prototypes. Four cases are at very different price points and priorities, shipping or about to ship, and each one makes a different bet about what the buyer actually wants.

The Jonsbo TK-0 bets on the "fish tank" aesthetic: 270-degree dual-curved glass panels wrapped around an aluminum and wood veneer frame, measuring 235mm by 250mm by 280mm. It's a Mini Tower, not a strict SFF cube, and it comes with four fan positions, multi-vent cooling, and a separate air intake channel for the power supply. Available at $129.99, it hasn't shipped yet, so nobody has one in hand yet. Builder chatter has already zeroed in on the walnut veneer and the curved glass as the draw, which makes the TK-0 as much a display piece as a functioning machine. GPU clearance caps out at 230mm, so enthusiast-tier cards need a tape measure before a credit card.

The Jonsbo C6-ITX takes the opposite bet: airflow over show. It's the same footprint as the mATX C6, wrapped in mesh on the side, top, and front panels, with a fabric carry handle for portability, and weighs a modest 2.50kg empty. The power supply placement was moved to the front of the case to accept a full-size ATX PSU up to 140mm long. That relocation is a direct answer to airflow complaints that trailed the original mATX C6, and it buys the case 170mm of CPU cooler clearance and 255mm of GPU clearance, enough room for shorter RTX 4070 Ti Super variants. Pricing and an exact release date aren't confirmed yet.

Thermaltake's TR100 SFF goes for GPU generosity above almost everything else in this tier. At 18.9 liters, it includes a PCIe 4.0 riser cable, fits GPUs up to 360mm, supports radiators up to 280mm, and includes a PCIe 4.0 riser cable. Priced from $129.99, it's the most accommodating case in this batch for anyone trying to fit a current flagship card into a box that small, and that single spec is the reason to pick it over the other three.

The NZXT H6, launched at Computex 2026 between June 2 and 5, needs a flag before anything else: it's a compact mid-tower. It's still relevant to anyone chasing the compact aesthetic without ITX's harder size constraints. It uses a dual-chamber layout to separate power supply heat and cable clutter from the main component area, wraps a single-piece curved tempered glass panel around the front, and angles its fans to push airflow directly over the GPU and CPU rather than just through the case in general. Ten 120mm fan mounts, an integrated adjustable GPU anti-sag bracket, and top-mount AIO support up to 360mm round out the spec sheet. Back-connect motherboard support is included, and at this point it's effectively mandatory for anything marketed as a 2026 build, not a premium feature anymore. The H6 runs $99.99, the H6 RGB+ runs $199.99, both come in black and white, and both carry a two-year warranty.

The cases that still set the standard for Mini-ITX builds

New announcements aside, a handful of cases have already earned their reputation through independent testing, and they remain the benchmarks anyone shopping in this category should measure against before getting distracted by a prototype with a screen built into the side panel.

The Fractal Design Terra, and its Jade and Graphite variants, has been named best Mini-ITX case overall for 2026 by PC Gamer, while Tom's Hardware recommends it specifically as the best design-focused option in the category. It pairs an aluminum outer shell with a real walnut front panel inside a 10.4-liter footprint, and it fits GPUs up to 322mm, enough for most RTX 4080 and RTX 5080 models. It ships with a PCIe 4.0 riser cable and a layout designed to make build access less painful than most cases this size. AIO support reaches up to 280mm mounted on top, though 240mm is the recommended path for anyone who wants to build without fighting the case. Two real constraints apply here: it takes SFX or SFX-L power supplies only, and CPU cooler height clearance is constrained by the case's compact interior and the GPU installed, which rules out a lot of high-TDP chip and air-cooler combinations before you even open the box.

The Hyte Revolt 3 has been cited as a top pick for LAN parties and as a strong budget option among Mini-ITX cases. It fits GPUs up to 335mm, supports AIOs up to 280mm, and holds two 2.5-inch SSDs plus one 3.5-inch drive. It ships with a built-in carry handle, a small detail until the moment you're actually hauling a PC to a LAN event and your hands are full. At $129 for the base variant, it's a genuinely strong value proposition.

Cooler Master's NR200P Max and NR200P V2 round out the field. Their tempered glass panel and full-length GPU support have kept them near the top of Mini-ITX recommendation lists, and the NR200P V2 in particular gets cited for the best performance-to-price ratio available in a gaming-focused ITX build.

FormD's T1 v2.1 ranks at the top of sff.gg's case listings and has built a strong reputation in the community. At 10 liters, it supports air cooling, AIO loops, and full custom liquid cooling configurations, with multiple internal layout options depending on what a builder is trying to fit.

The thermal reality of putting high-end components in a small box

None of this changes a basic physical fact: smaller volumes trap more heat. Even mesh-paneled ITX cases running high-performance fans still run 3 to 7 degrees hotter than mid-tower cases running identical components. That gap is thermodynamics, and no amount of clever panel geometry erases it. It's thermodynamics, and no amount of clever panel geometry erases it.

GPUs feel this more sharply than any other component. A full-size graphics card in an ITX case typically runs 5 to 10 degrees warmer than the same card sitting in an equivalent ATX tower. For most quality GPU coolers, that range still sits comfortably inside safe operating limits, so it isn't a crisis figure by itself. It becomes a real concern on budget GPU variants with weaker coolers, where thermal throttling can kick in earlier than the spec sheet would suggest. High-TDP CPUs paired with cases that cap cooler height, the Terra's 48mm to 77mm window being the clearest example, run into the sharper version of this problem, since there's simply less vertical clearance to dissipate heat before it backs up into the rest of the case.

Case design is where manufacturers are actually fighting this, and the fight shows up in specific engineering choices rather than spec-sheet bragging. Dual-chamber layouts, seen in the NR200P and the NZXT H6, physically wall off power supply heat from the CPU and GPU. Mesh-first designs, like the C6-ITX, maximize passive and active airflow by cutting solid panel surface area wherever the structure allows it. Power supply placement changes how air moves through the whole case, not just around the PSU itself: the C6-ITX's front-mounted PSU bay is sized for a full ATX unit up to 140mm. Fan angling, the H6's front-right fans pointed to direct airflow straight over the GPU and CPU rather than diffusing it through the chassis, is a deliberate thermal decision.

None of these solve the volume they generate. They manage it, and the case you pick determines how well that management holds up under a sustained load rather than a benchmark run.

Mapping a case choice to a budget and build goal

Going small costs money, and pretending otherwise sets a budget up to fail before parts even ship. Building compact adds roughly $180 to $290 compared to an equivalent Micro-ATX build, largely because Mini-ITX motherboards on current platforms (AM5/B650E or LGA1851/H670) run $180 to $260 on their own. That premium is the price of admission, and any budget plan for an ITX build needs to account for it at the planning stage, not discover it at checkout.

For a budget build in the $800 to $1,100 range, the case choices line up cleanly: the Hyte Revolt 3 costs $129, the Jonsbo TK-0 costs $129.99 (once its October 10 release actually arrives), or the Thermaltake TR100 SFF costs $129.99, all at the same price point. Pairing any of them with a Ryzen 5 9600X-class CPU and a mid-range GPU keeps the platform premium proportionate to the rest of the build rather than letting the case eat the whole budget on its own.

Stepping up to a $1,210 to $1,650 mid-range or performance build, the NR200P V2 and the Fractal Design Terra are the anchors that make sense, both backed by independent testing rather than spec sheets alone. A CPU budget of $220 to $280 fits a Ryzen 7 8700G or Core i5-14600K class chip comfortably alongside either case without unbalancing the build toward the processor and starving the rest of it.

At the enthusiast end, where the case functions as a display object as much as a machine, the FormD T1 v2.1, the Lian Li A4-H2OX5, and the Fractal Design Terra Jade are the names that keep coming up, and for good reason: none of them are the cheapest route to strong performance. For a builder whose finished PC sits on a desk in plain view as often as it runs a game, that tradeoff is simply the price of admission. It's the entire point of building in this category.
